HT32F61355 48LQFP

US$2.17
In stock
Quantity
1000 pieces
Product ID
HT32F61355-48LQFP
DESCRIPTION

The HT32F61355 is a 32-bit microcontrollers based around an Arm® Cortex®-M0+ processor core. The device which with high performance and high quality audio can be used to implement superior sound effect functions. It is suitable for use in higher level voice and musical smart toys, electronic synthetic musical instruments and various smart creative products, etc.

The HT32F61355 includes a 16-bit high performance D/A converter which provides a stereophonic output and an MIDI engine. Under a maximum system frequency of 48MHz, it supports up to 32 channels of music synthesis at one time. Holtek also provides an Audio Workshop to assist users with their product development.

NOTE
  1. The product image is for showing the product appearance, the pin count shown may not match the product pin count.

Quantity Discounts refresh image
Select Quantity Discount Unit price
1-9 - US$2.17
10-99 15% US$1.84
100-499 25% US$1.63
500+ 35% US$1.41
For more quantity discounts please contact us
Follow Us for More Updates!
FEATURES
  1. 32-bit Arm® Cortex®-M0+ processor core
  2. Up to 48 MHz operating frequency
  3. 0.93 DMIPS / MHz (Dhrystone v2.1)
  4. 24-bit SysTick timer
  5. Up to 128 KB on-chip Flash memory for instruction/data and options storage
  6. Up to 32 simultaneous sounds
  7. Output sampling frequency up to 50 kHz
  8. Waveform data lengths of 8, 12 or 16 bits
  9. Up to 16 external analog input channels
  10. Two 16-bit high resolution D/A converters with excellent frequency response characteristics and good power consumption for stereo audio output
PRODUCT SERIES
DEVELOPMENT TOOL
  1. Integrated Serial Wire Debug Port (SW-DP)
  2. Support ISP (In-System Programming), IAP (In-Application Programming), ICP (In-Circuit Programming)
  3. Debug Adapter : e-Link32 Pro
  4. Development Environment : Keil uVision, IAR EWARM
RESOURCES
  1. MCU : Holtek HT32F61355, 32-bit Arm® Cortex®-M0+ Music Synthesizer MCU, including datasheet, package dimension, etc.
More Information
HS Code (reference) 8542.31.0000
