Relay Module BMP75M131

US$2.90
In stock
Quantity
90 pieces
Product ID
BMP75M131

When developing smart home appliances, such as controlling motors or desk lamps, it's necessary to control the power on/off for high voltage or alternating current (AC). However, handling high-voltage directly by humans is dangerous. This is where relays come into play. The BMP75M131 is a single-channel relay module that can safely handle high-voltage with maximum load current 5A at 28VDC, 7A at 125VAC, and 5A at 240VAC.

Quantity Discounts refresh image
Select Quantity Discount Unit price
1-9 - US$2.90
10+ 5% US$2.76
For more quantity discounts please contact us
Follow Us for More Updates!
DESCRIPTION

A typical relay module uses an I/O signal to toggle its state. When there's a requirement to control eight relays, it will occupy eight I/O pins on the development board.

However, besides the I/O control mode, the BMP75M131 also provides networking mode. In networking mode, the development board can switch the states of each relay via I2C interface. Up to eight BMP75M131 relay modules can be cascaded concurrently, and only one module needs to be connected to the development board.
The operation mode can be selected by using the jumper on the BMP75M131. When cascading, the jumpers on each BMP75M131 module need to be disconnected (removed).

There is a BMCOM on the BMP75M131 designed for direct connection to the BMduino development board, such as BM53A367A. You can use the product with other development boards, such as Arduino UNO, as well.

Operation modes comparing

I/O control mode Networking mode
Mode selection
(IO_mode Jumper)
Short-circuit the jumper. Removed the jumper.
When cascading, jumpers on each module
need to be removed.
Cascading Not cascadable.
Require individual controlled.
Cascadable (up to eight modules)
Only one module needs to be connected
to the development board.
Development control Control relays through I/O pins.
Switch on relays in high level.
Issue commands through I2C interface
to control each cascaded relay.
PRODUCT FEATURES
  1. Input voltage: 3.0V~5.5V
  2. Operating current:
    - 110mA @5V (relay switched on)
    - 3mA @5V (relay switched off)
  3. Maximum load current:
    - 5A @28VDC
    - 7A @125VAC
    - 5A @240VAC
  4. Operation mode: I/O control mode, Networking mode (select via jumper)
  5. Provide cascaded interface, and can cascade up to 8 modules
  6. Interface: I2C (address: 0x15)
  7. Dimension: 50.11 x 29.5 x 20 mm
  8. Net weight: 15.9g
  9. Product includes: BMP75M131 x1, 2x2P header x1
HARDWARE OVERVIEW
PIN DESCRIPTION
Pin Pin name Function
1 NC -
2 SCL I2C: clock line
3 SDA/IO I2C: data line
I/O: relay control line
4 VDD Power supply: 3.0V~5.5V
5 GND Ground
6 GND Ground
7 VDD Positive power
8 ST_O Cascade status output
9 TRX Cascade single bus communication pin
10 VDD Positive power
11 GND Ground
12 ST_I Cascade status input
13 TRX Cascade single bus communication pin
14 NC Relay close
15 COM Relay common pin
16 NO Relay open
RESOURCES
  1. MCU : Holtek HT66F2040, Small Package A/D Flash MCU with EEPROM, including datasheet, package information, etc.
