Home Generic TRX development board with LCM (no MCU) BCE-GENTrx0-001
  • Home
  • Generic TRX development board with LCM (no MCU) BCE-GENTrx0-001
main product photo

Generic TRX development board with LCM (no MCU) BCE-GENTrx0-001

US$27.00
In stock
Quantity
13 pieces
Product ID
BCE-GENTrx0-001
DESCRIPTION

The BCE-GENTRX0-001 is a development board with LCM. It has no MCU on the board. You can evaluate RF modules easily with it.

It's easy to use. Connect the RF module to the development board via a breakout board, program the example code of the RF module into the module by e-Link32 Pro or e-Link, and supply the power.

Product information

Dimension: 110 x 70 x 26 mm
Net Weight: 46.8g

Add to Wish List
Email
Follow Us for More Updates!
PRODUCT FEATURES
  1. Provides four types of power supply: external power, Micro USB, batteries, DC power
  2. Includes one LCM module, but no MCU on the board
  3. Includes both of the e-Link and e-Link32 Pro interfaces
  4. Supports multiple RF modules

Differences between TRX development boards

HARDWARE OVERVIEW

 Power Supply

Select one of these power sources below, put the jumper on the corresponding pin header, and turn on the power switch.
  1. External power (VEXT): connect to external power which does not exceed 3.6V.
  2. Micro USB:
    (1) LDO33: connect to 3.3V power, and move the J2 jumper to USB.
    (2) VUSB: connect to 5V power.
  3. Batteries (BATT): put two 1.5V AA batteries in the holder.
  4. DC power (LDO33): connect the power to the DC jack which does not exceed 12V, and move the J2 jumper to DC JACK.
RESOURCES
  1. Application note: AN0624EN, BM67C741-1 Application Note, including BCE-GENTRX0-001 hardware overview, BM67C741-1 library, etc.
More Information
HS Code (reference) 8517.79.00.00-6
User Guide (964.41 kB)
Schematic (73.71 kB)
PCB layout (661.25 kB)
Related Products
BC66F3662 Sub-1GHz FSK/GFSK Transceiver Module Breakout Board BCT-3662-001
